Product Details
the Andreae has been the reference filter on the market. It remains the most universal and common filter in use. Our Original is made with 2 layers of heavy “kraft” paper, punched, pleated and glued together with 2 built-in extension limiters. Thanks to these limiters, the maximum load capacity is guaranteed. The Original is the filter for all paint types.
Specification
| LOAD [KG/M3] [LBS/SQFT] | ||
| Lacquers 10kg / m2 2lbs / sqft |
High Solids 12kg / m2 2.4lbs / sqft |
Polyester 13kg / m2 2.5lbs / sqft |
| EFFICIENCY [%] | ||
| Lacquers 93.10 % |
High Solids 98.20 % |
Polyester 97.80 % |
| RECOMMENDED AIR VELOCITY | ||
| 0.5 to 1 m / s | ||
| PRESSURE DROP AT/BY | ||
| 0.5 m/s 20 pa |
0.75 m/s 30 pa |
1.0 m/s 40 pa |
| MAX. RECOMMENDED PRESSURE DROP | ||
| 128 pa ( possible up to 256 ) | ||
